Kwikset 687 DAXP S US15
Kwikset
Send Print

Kwikset 687 DAXP S US15 Combination Lockset, Dakota Design, Satin Nickel, 3 Grade, Re-Key Technology: SmartKey

  • Model Number: 687 DAXP S US15
  • Store SKU: loading

  • Kwikset 687 DAXP S US15 Combination Lockset, Dakota Design, Satin Nickel, 3 Grade, Re-Key Technology: SmartKey

    • Supplier SKU: loading
    • Web SKU: 102723858
  • Product Code: 88335126386
    • Availability:
Kwikset 687 DAXP S US15

Kwikset Combination Lockset, Design: Dakota, Satin Nickel, Security Grade: 3, Re-Key Technology: SmartKey, Keyway Type: KW1, Door Handing: Reversible, Faceplate Size: 1 x 2-1/4 in, Backset Size: 2-3/8, 2-3/4 in, Bolt Throw Size: 1/2 in, Cylinder Type: 5-Pin Tumbler, Deadbolt Latch Throw: 1 in, Door Thickness: 1-3/4 in, Edge Bore Diameter: 1 in, Cross Bore Diameter: 2-1/8, 1-1/2 in, Strike Size: 1 x 2-1/4 in, Strike Type: Full Lip Round Corner, Center to Center: 5-1/2 in, Includes: (2) Keys, Deadbolt and Full Lip Round Strike

Backset Size : 2-3/8, 2-3/4 in
Bolt Throw Size : 1/2 in
Center to Center : 5-1/2 in
Cross Bore Diameter : 2-1/8, 1-1/2 in
Cylinder Type : 5-Pin Tumbler
Deadbolt Latch Throw : 1 in
Design : Dakota
Door Handing : Reversible
Door Thickness : 1-3/4 in
Edge Bore Diameter : 1 in
Faceplate Size : 1 x 2-1/4 in
Finish : Satin Nickel
Includes : (2) Keys, Deadbolt and Full Lip Round Strike
Keyway Type : KW1
Plainbolt Latch Throw : 1/2 in
Re-Key Technology : SmartKey
Security Grade : 3
Strike Size : 1 x 2-1/4 in
Strike Type : Full Lip Round Corner
  • Featuring SmartKey Security™, which protects against advanced break-in techniques and allows you to re-key your lock yourself in seconds
  • SmartKey Security™ re-key technology is compatible with Kwikset (KW1) keyway
  • Interior knob with universal handing
  • Fits both right-handed and left-handed doors
  • Latch has two interchangeable faceplates
  • Latch has adjustable backset 2-3/8 to 2-3/4 into fit all standard door preparations
  • Locking mechanism functions with turn piece on the interior of the lock
  • Easily installs in minutes with just a screwdriver
