Eaton Wiring Devices
Eaton Wiring Devices 1709-SP Electrical Plug, Straight Blade, 0.25 to 0.6 in, 2-Pole, 15 A, 125 V, NEMA: NEMA 5-15
- Model Number: 1709-SP
- UPC: 785007862867
-
Store SKU:
-
Eaton Wiring Devices 1709-SP Electrical Plug, Straight Blade, 0.25 to 0.6 in, 2-Pole, 15 A, 125 V, NEMA: NEMA 5-15
-
-
Supplier SKU:
- Web SKU: 101878259
-
Supplier SKU:
- Product Code: 78500786286
-
Promo Price:
Eaton Wiring Devices 1709-SP
Commercial-grade thermoplastic rubber plugs solid brass plug blades are firmly embedded in body. Terminal screw clamps are designed to contain wire and prevent binding. Terminal screws backed out ready for wiring. Terminals in individual chambers to positively insulate conductors. Combination slot/Phillips head mounting and terminal screws ease installation with power screwdrivers.
| Cable/Wire Size | : | 0.25 to 0.6 in |
| Color | : | Black |
| Current Rating | : | 15 A |
| Grounding Type | : | Grounded |
| Material | : | Thermoplastic Rubber |
| NEMA Configuration | : | NEMA 5-15 |
| Number of Poles | : | 2 |
| Number of Wires | : | 3 |
| Type | : | Straight Blade |
| Voltage Rating | : | 125 V |
- Solid brass plug blades are firmly embedded in body
- Terminals in individual chambers to positively insulate conductors
- Terminal screw clamps are designed to contain wire and prevent binding
- Terminal screws are backed out and ready to wire
