Romex® 10/2NM-WGX250
Romex®
Send Print

Romex® 10/2NM-WGX250 Building Wire, 10 AWG Wire, 2-Conductor, 250 ft L, Copper Conductor, PVC Insulation, Nylon Sheath

  • Model Number: 10/2NM-WGX250
  • UPC: 032886163104
  • Store SKU: loading

  • Romex® 10/2NM-WGX250 Building Wire, 10 AWG Wire, 2-Conductor, 250 ft L, Copper Conductor, PVC Insulation, Nylon Sheath

    • Supplier SKU: loading
    • Web SKU: 103036784
  • Product Code: 206037
    • Availability:
Romex® 10/2NM-WGX250

Romex® Building Wire, NM-B, Wire Size: 10 AWG, 250 ft L, Number of Conductors: 2, Strands per Conductor: 1, Conductor Material: Copper, Conductor Insulation: PVC, Stranded/Solid: Solid, Sheath Material: Nylon, Sheath Color: Orange, Sheath Diameter: 0.505 in, 600 V, 30 A, Resistance: 1.04 Ohm, Bend Radius: 1.2 in, Operating Temperature: 90 deg C

Bend Radius : 1.2 in
Conductor Insulation : PVC
Conductor Material : Copper
Current Rating : 30 A
Length : 250 ft
Number Of Conductors : 2
Operating Temperature : 90 deg C
Resistance : 1.04 Ohm
Sheath Color : Orange
Sheath Diameter : 0.505 in
Sheath Material : Nylon
Stranded/Solid : Solid
Strands per Conductor : 1
Type : NM-B
Voltage Rating : 600 V
Wire Size : 10 AWG
  • Copper conductors are annealed copper
  • Stranded conductors are compressed stranded
  • Romex® Brand SIMpull NM-B cable is designed for easier pulling, resulting in easier installation
  • Made in America
