Mrcool DIY-24-HP-C-230D25-O
Mrcool
Send Print

Mrcool DIY-24-HP-C-230D25-O Mini-Split Condenser Outdoor Unit, 208/230 V, 24,000 Btu/hr BTU, 2 ton Tons, 22.7 SEER

  • Model Number: DIY-24-HP-C-230D25-O
  • UPC: 840255586979
  • Store SKU: loading

  • Mrcool DIY-24-HP-C-230D25-O Mini-Split Condenser Outdoor Unit, 208/230 V, 24,000 Btu/hr BTU, 2 ton Tons, 22.7 SEER

    • Supplier SKU: loading
    • Web SKU: 103840664
  • Product Code: 84025558697
    • Availability:
Mrcool DIY-24-HP-C-230D25-O

Taking on an HVAC installation yourself might seem daunting, but the 5th generation MRCOOL DIY® 24K Btu 22.7 SEER ductless heat pump single zone mini-split condenser is built specifically for easy, do-it-yourself setup. With no special tools or professional experience needed, this system is ideal for heating and cooling areas between 750 to 1000 sq-ft. The pre-charged 25 ft QuickConnect® line set simplifies installation by eliminating the need for vacuuming, while the included DIYPro® cable adds extra durability, replacing traditional electrical conduit to protect against weather, animals and yardwork hazards. With multiple control options, managing your comfort is effortless. Adjust settings using the included remote, the SmartHVAC app on Apple or Android devices or go hands-free with voice control via Amazon Alexa and Google Assistant. For homes near the coast, the Gold Fin® condenser enhances corrosion resistance, ensuring lasting performance. This system is packed with features to maximize efficiency and convenience. The timer function helps regulate energy use, while auto mode maintains your preferred temperature with no extra effort. If power is lost, the unit automatically restores previous settings. Plus, the anti-mildew function helps prevent moisture build-up inside the air handler. Engineered for long-term reliability, the 5th generation MRCOOL DIY® mini-split comes with an industry-leading warranty, including a limited lifetime warranty, 7 years compressor coverage and a 5 years parts warranty. Combining user-friendly installation with advanced technology, this system delivers lasting comfort with ease.

BTU Rating : 24, 000 Btu/hr
Color : White
Compressor Type : Rotary
Heating/Cooling Stage : 1
Line Set Length : 75 ft
Liquid Line Diameter : 3/8 in
Minimum Circuit Current : 24 A
Noise Level : 58.5 dBA
Overall Dimensions : 31.89 in H x 37.24 in W x 16.14 in D
Power Supply : 208/230 V
Refrigerant Type : R-454B
SEER Rating : 22.7
Suction Line Diameter : 5/8 in
Tons of Refrigeration : 2 ton
